电线电缆网 > 汽车线缆 > UL2263 Standard for Electric Vehicle Cable（完整版）
UL2263 Standard for Electric Vehicle Cable - 无图版
xutong001 --- 2022-10-08 17:08:15
1
求UL2263标准
俊辰 --- 2022-10-09 08:19:58
2
Style 2263
Multiconductor Cable using Non-Integral Jacket.
RATING | |||
60 deg C, 300 Vac (Jacket), 600 Vac (Insulation), Horizontal flame. | |||
CONDUCTOR | |||
26 AWG - 16 AWG, solid or stranded. | |||
INSULATION | |||
Extruded PE, 30 mils minimum average thickness, 27 mils minimum thickness at any point. | |||
ASSEMBLY | |||
Three conductors. | |||
SHIELD | |||
Over one or both insulated conductors. Shall consist of 36 AWG - 30 AWG copper strands applied as a wrap or braid. | |||
JACKET | |||
Extruded PVC, 15 mils minimum average thickness, 12 mils minimum thickness at any point or non-extruded lacquered braid. | |||
STANDARD | |||
Appliance Wiring Material UL 758. | |||
MARKING | |||
General. | |||
USE | |||
Internal Wiring. |
wzg196 --- 2022-10-09 09:38:47
3
求最新标准UL2263-Standard for Electric Vehicle Cable（电动汽车线缆标准）于2022年05月09日发布第一版。
